Website Contribution Guide (MkDocs Material)

Welcome! This page shows everything you need to add or edit pages on our docs site — no prior experience required.

0) TL;DR (10-minute checklist)

Install: pip install mkdocs mkdocs-material
Clone repo → open the folder.
Run locally: mkdocs serve → open http://127.0.0.1:8000
Create your page under docs/... (e.g., docs/tutorials/my_page.md).
Add it to the sidebar in mkdocs.yml under nav:.
Write content (use examples below for links, images, videos, math, code).
Save → preview refreshes automatically.
Commit & push → site auto-deploys.

1) Install & run locally

# 1) Install once
pip install mkdocs mkdocs-material

# 2) In the repo root:
mkdocs serve
# Open the link shown in the terminal (usually http://127.0.0.1:8000)

If your page doesn’t show in the sidebar, you probably forgot to add it to mkdocs.yml (see section 5).

2) Repo structure (what goes where)

.

├─ mkdocs.yml # site config & sidebar (nav)

└─ docs/ # all content lives here

├─ index.md # homepage

├─ media/ # images & videos you upload

├─ tutorials/ # tutorial pages

├─ departments/ # team/tech sections

├─ overrides/ # optional CSS tweaks

└─ javascripts/ # optional JS (e.g., MathJax helper)

Rules - Put Markdown pages inside docs/. - Put images/videos in docs/media/. - Use relative paths in links (don’t start with /, don’t include docs/).

3) One-time config (math, captions, responsive iframes)

Add these to mkdocs.yml if not already:

theme:
  name: material

markdown_extensions:
  - attr_list        # width=..., target=..., etc.
  - md_in_html       # lets Markdown work inside <figure>…</figure>
  - admonition
  - pymdownx.details
  - pymdownx.superfences
  - pymdownx.tabbed:
      alternate_style: true
  - pymdownx.tasklist:
      custom_checkbox: true
  - pymdownx.arithmatex:
      generic: true

extra_javascript:
  - javascripts/mathjax.js
  - https://cdn.jsdelivr.net/npm/mathjax@3/es5/tex-mml-chtml.js

extra_css:
  - overrides/styles.css

Create docs/javascripts/mathjax.js:

window.MathJax = {
  tex: { inlineMath: [['$', '$'], ['\\(', '\\)']] },
  options: { skipHtmlTags: ['script','noscript','style','textarea','pre'] }
};

Create docs/overrides/styles.css:

/* 16:9 responsive iframe wrapper for YouTube/Vimeo */
.video { position: relative; padding-top: 56.25%; height: 0; overflow: hidden; margin: 1rem 0; }
.video iframe { position: absolute; inset: 0; width: 100%; height: 100%; border: 0; }

/* Optional: figure + caption styling */
figure { text-align: center; margin: 1rem 0; }
figcaption { margin-top:.4rem; font-size:.9rem; color: var(--md-default-fg-color--light); }

4) Create a page

Create docs/tutorials/webpage_setup.md (for example). Start with:

# Page Title

A few sentences describing what this page covers.

## Section heading

Content goes here.

Open mkdocs.yml and edit the nav: section. Use paths under docs/.

nav:
  - Home: index.md
  - Tutorials:
      - LiDAR Setup: tutorials/lidar-setup.md
      - Webpage Setup: tutorials/webpage_setup.md   # ← your new page

Case-sensitive! perception ≠ Perception.
If you forget this step, your page exists but won’t appear in the sidebar.

6) Write content: the essentials

A) Links

Link to another page (path is relative to this file):

[Home](../../index.md)
[LiDAR Setup](../../tutorials/lidar-setup.md)
[Perception overview](../perception/overview.md)

Link to a section on another page (anchors are kebab-case):

[Calibration steps](../../tutorials/lidar-setup.md#calibration-steps)

Or set your own id:

## Calibration steps {#calib}
[Jump there](../../tutorials/lidar-setup.md#calib)

Open in new tab:

[External site](https://eufs.eu){ target=_blank rel=noopener }

Inside shown links
```
<link>
```

B) Images

Put images in docs/media/ and use relative paths:

![Cone map](../../media/wlco.png){ width=600 loading=lazy }

Clickable thumbnail → full image:

[![Cone map](../../media/wlco.png){ width=320 }](../../media/wlco.png){ target=_blank }

Captioned figure (recommended):

<figure markdown>
  ![Cone map](../../media/wlco.png){ width=600 loading=lazy }
  <figcaption>Figure 1: Cone clustering output from the VLP-16.</figcaption>
</figure>

C) Videos

YouTube (privacy mode + responsive)

<div class="video">
  <iframe
    src="https://www.youtube-nocookie.com/embed/VIDEO_ID?rel=0"
    title="Demo"
    loading="lazy"
    allow="accelerometer; autoplay; clipboard-write; encrypted-media; gyroscope; picture-in-picture; web-share"
    allowfullscreen></iframe>
</div>

Online MP4 (direct URL or local file in docs/media/)

<video controls preload="metadata" width="100%" playsinline poster="../../media/thumbnail.jpg">
  <source src="../../media/demo.mp4" type="video/mp4">
  Your browser doesn’t support HTML5 video.
</video>

Autoplay (mobile-friendly):

<video controls autoplay muted loop playsinline width="100%">
  <source src="https://example.com/video.mp4" type="video/mp4">
</video>

If you see “CORS” errors with remote MP4s, download the file into docs/media/ and link to it locally.

D) Math (LaTeX)

Inline: $\theta^* = \arg\max_\theta p(\mathcal{D}\mid\theta)$ → $\theta^* = \arg\max_\theta p(\mathcal{D}\mid\theta)$

Block:

$$
a = k_p \, e \;+\; k_i \sum (e\,\Delta t)
$$

E) Code blocks

Fenced code: `mdpython def f(x): return x*x

Tabs (multi-language): ~~~md

Python

python print("hello")

C++

cpp std::cout << "hello\n"; ~~~

Admonitions: ~~~md

Note

This is a helpful callout.

~~~

7) Style & formatting tips

Headings: Start with a single # Title at top, then ##, ###, …
Images: Prefer PNG/JPG for photos, SVG/PNG for diagrams. Use alt text.
Links: Use relative paths, never start with /, and don’t include docs/.
Filenames: lowercase-with-dashes.md is easiest to link.
Sections: Use clear headings; the right-hand “Table of contents” will follow as you scroll.
Search: Full-text (except very common “stop words” like “we”, “the”, …).

8) Git workflow (basic)

~~~bash

Create a new branch (recommended)

git checkout -b docs/my-new-page

Add your file(s)

git add docs/tutorials/webpage_setup.md mkdocs.yml

Commit

git commit -m "docs: add Webpage Setup tutorial"

Push

git push -u origin docs/my-new-page ~~~

Open a Pull Request on GitHub. After merge to master (or the main branch), the site rebuilds automatically via GitHub Actions.

9) Troubleshooting

Problem	Likely cause	Fix
Page doesn’t show in sidebar	Not in `mkdocs.yml` `nav:`	Add the file path under `nav` (case-sensitive)
Image not loading	Wrong relative path or uppercase/lowercase mismatch	Check path from the current file → `../../media/your.png`
Video won’t play (remote MP4)	CORS blocked	Download to `docs/media/` or host on a CDN that allows cross-origin
Math not rendering	Missing config	Ensure `pymdownx.arithmatex` + MathJax are in `mkdocs.yml`
ToC headings in left sidebar	`toc.integrate` enabled	Remove `toc.integrate` from theme features
All dropdowns open by default	`navigation.expand` enabled	Remove `navigation.expand` from theme features

10) Quick reference: relative paths

From page…	To `docs/media/wlco.png`
`docs/index.md`	`media/wlco.png`
`docs/tutorials/lidar-setup.md`	`../media/wlco.png`
`docs/departments/perception/theory.md`	`../../media/wlco.png`

11) Example page template (copy into a new file)

~~~md

My New Page

Brief description of what this page covers.

1. Overview

Here is an inline equation $\theta^* = \arg\max_\theta p(\mathcal{D}\mid\theta)$.

latex $$ a = k_p\,e + k_i \sum (e\,\Delta t) $$

2. Image with caption

3. Video

4. Useful links

Back to Home

5. Code

python def normalize(v): return v / (abs(v) + 1e-8) ~~~

12) Before you push

Run locally: mkdocs serve
Fix warnings (missing pages in nav, bad links)
Check images/videos load
Commit & push ``` ::contentReference[oaicite:0]{index=0}
